With the increasing number of private cars, every city is troubled by the difficulty of parking. The problem of nowhere to park vehicles is an inevitable result of social, economic and transportation development to a certain extent. Today, let's talk about the pit-type simple lifting stereo garage.
In recent years, the number of new energy vehicles in ownership has been on the rise. By the end of 2024, the number of new energy vehicles in ownership in China had reached 31.4 million, accounting for 8.9% of the total number of vehicles in the country. As many cities are building new residential communities and commercial centers, in order to resolve the conflict between the large land area occupied by ground parking and the limited land resources, the development of three-dimensional mechanical parking equipment has become an effective way to address this conflict. With its unique feature of small average occupied area, the stereo garage has gradually been accepted by a large number of users.
The working principle of the pit-type simple lifting stereo garage is that the upper and lower parking spaces are lifted and lowered as a whole. The middle and lower parking spaces are located in the pit, and the upper parking space is level with the ground. The depth of the pit is usually 4.5 meters, and the height difference between the middle floor and the lower floor is 1.7 meters. The vehicle capacity size (L×W×H) is 5000mm×1850mm×1550mm. The vehicle capacity weight is within 2.35 tons. As automobile manufacturers continue to adjust the specifications and sizes of vehicles, the vehicle capacity sizes of mechanical parking garages also need to be adjusted simultaneously.
Equipment Features
1. It saves occupied area significantly by avoiding the scattered layout of traditional open-air parking lots, makes full use of underground space—such as digging reasonable-depth underground parking levels to avoid wasting surface land—and thus effectively increases the number of parked vehicles within a limited land area, greatly alleviating the problem of "difficult parking" in densely populated areas like urban communities and commercial districts.
2. It has functions such as dust prevention and rain prevention for the middle and lower parking spaces.
3. Since the middle and lower floors of the equipment are lowered into the ground, when the parking spaces are built in front of buildings on the sunny side, such parking spaces will not affect the lighting of residents on the low and middle floors.
4. As this set of equipment adopts a lifting structure, its structure is relatively simple. At the same time, it can be operated via buttons and IC cards, so it is easy to use.
Safety Aspect For the pit-type simple lifting stereo garage, its safety protection relies on the support of various types of dedicated devices, specifically including emergency stop devices, anti-fall devices, overcurrent protection devices, upper and lower over-limit protection devices, entrance photoelectric detection devices, upper and lower positioning switches, wheel stoppers, power-off braking devices, over-length detection devices and safety interlock devices. These devices play a role in multiple dimensions such as operation control, risk blocking and abnormal early warning, which can effectively address potential safety issues such as emergency shutdown of equipment, falling of personnel or vehicles, circuit overload, excessive operation range and foreign object intrusion, and effectively improve the overall safety protection level of the stereo garage.
It strengthens safeguards against risks like vehicle scratches during parking, structural malfunctions, and foreign object intrusion. This not only reduces accident rates but also extends the garage’s service life, ensuring more reliable, secure parking experiences for users daily.
